A-Electrical Range

A12 E, A13 JE, A16 JE, A18 JE
  • Proposional Control
  • 2 whiles drive


  • Flashing warnig light
  • Control box protection cap
  • 230v Suply with plug on the platform
  • 230v Suplay with plug on the platform with earth-leakage circuit beraker
  • Grip foam-filled tyres (16/18m)
  • Hydrolic cage rotation 70° +70° (A12E)
  • Super elastic none – marking white tyres (A12E)
A-Electrical RangeA12 EA13 JEA16 JEA18 JE
Max Platform Heightmm1000011001400015760
Max Working Heightmm12000131001600017760
Total capacity /n° of personskg200200230230
Max Working Out Reachedm6.
Degree Turret Rotation180° +180°180° +180°180° +180°180° +180°
Hydrolic Cage RotationOption70° +70°70° +70°70° +70°
Battery chargerV/Ah24/2524/2524/2524/25
Oil tank capacityl30303030
Drive speed (safety/fast)Km/H0,60/30,60/30,60/30,60/3
Inclination long. /trasv°3°/2°3°/2°3°/1,2°3°/1°
Total weight kg3900/4200*540073008250
